RED2433 is an advanced LED Controller IC for high efficiency low-cost LLC converters and is intended for high frequency CC LED drivers up to 80W.
Advanced LED Controller IC for high efficiency low-cost LLC converters with bipolar transistors and integrated PFC PSR - +/-3% Primary Side Regulation of LED current and voltage with no Flicker Overtemperature output current foldback for high temperature survival Lowest output current ripple <0.3%. Flicker Index typically 0.0004 Protection modes: a. Overload b. No-Load c. Over-temperature fault latch & output current foldback Automatic dead-time control and capacitive mode protection Small SOT23-6 IC package
Datasheet
Key Features
Order Details
Code RED2433AL-TR7 Package SOT23-6 Tape & Reel
•	RED2433 50W 1A2 Design Report (1690kB)  •	RED2433 50W 1A2 Design Report (1690kB) •	 Reference Design  Check Application Notes Check Application Notes Order Order Low Power LED Controller for LLC converters RED2433
•	RED2433  (347kB)   •	RED2433  (347kB)           LED Driver ICs
