RED2822 is an advanced resonant controller IC for high efficiency CC LED drivers with flicker free linear dimming. It is suitable for low-cost passive PFC systems up to 45W and high power active PFC systems up to 250W.
Advanced Resonant Controller IC for high efficiency LED drivers. Upgrade to RED2821 Primary-side Constant Current regulation reduces component count and enables easy interfacing with digital control (Bluetooth, Zigbee, DALI MCU, PWM) Optimised for: o Passive PFC LED drivers up to 45W o Active PFC LED drivers up to 200W. RED2822 works with any APFC controller IC 50% duty cycle, variable frequency control of resonant half-bridge +/-5% Primary Side Regulation of LED current and voltage with no Flicker Protection modes: a. Overload output including short-circuit b. No-Load Output c. Over-temperature foldback & shutdown Low standby power Small SO8 IC package
Datasheet
Key Features
Order Details
Order code: RED2822AD-TR13 SO8 package on 13” tape & reel
•	Wireless RED2822 38W LED driver with Qorvo QPG6100    Reference Design  Check Application Notes Check Application Notes Order Order Resonant Controller for CC LED Drivers RED2822
•	RED2822AL Rev01 Production (517kB)   •	RED2822AL Rev01 Production (517kB)         LED Driver ICs
RediSem Ltd. Science Park Shatin Hong Kong Tel. +852 2607 4141 Fax. +852 2607 4140 Careers | Contact © Copyright 2017-2020 RediSem Ltd.
Resonant Controller for CC LED Drivers RED2822
RED2822 is an advanced resonant controller IC for high efficiency CC LED drivers with flicker free linear dimming. It is suitable for low-cost passive PFC systems up to 45W and high power active PFC systems up to 250W.
Advanced Resonant Controller IC for high efficiency LED drivers. Upgrade to RED2821 Primary-side Constant Current regulation reduces component count and enables easy interfacing with digital control (Bluetooth, Zigbee, DALI MCU, PWM) Optimised for: o Passive PFC LED drivers up to 45W o Active PFC LED drivers up to 200W. RED2822 works with any APFC controller IC 50% duty cycle, variable frequency control of resonant half-bridge +/-5% Primary Side Regulation of LED current and voltage with no Flicker Boost current feature to ensures reliable startup with constant power loads Protection modes: a. Overload output including short-circuit b. No-Load Output c. Over-temperature foldback & shutdown Low standby power Small SO8 IC package
